Garmin Gpsmap76

The GPSMAP76 is designed to provide precise GPS positioning using correction data obtained from the Wide Area Augmentation System. This unit features a built-in quad helix antenna for superior reception and can provide position accuracy to less than three meters when receiving WAAS corrections.

The GPSMAP76 has an internal memory capacity of eight megabytes. In addition, it comes with a built-in basemap of cities, coastlines, lakes, rivers, interstates, and interstate exit information and a database of nautical navaids.

This unit has eight megabytes of internal user memory for storing optional MapSource® — detailed maps, including marine cartography. This memory is preloaded from the factory with worldwide cities (populations greater than 200,000) and nautical navigation aids such as lights, buoys, sound signals and day beacons. The GPSMAP76 is also preloaded with tide data for the United States.

An extra-large display measuring 1.6"W x 2.2"H gives users a clear view of information, while a waterproof case means the GPSMAP76 will keep working well even if it's been submerged in water. Even more amazing, this unit will actually float if accidentally dropped in the water.

(Are you having trouble setting your unit's date? Please see our important FAQ .)

Package includes:

• GPSMAP76 receiver
• Basemap:
  Americas Highway or
  Atlantic Highway or
  Pacific Highway
• PC interface cable
• Wrist strap
• Owner's manual
• Quick reference guide

Optional Accessories for GPSMAP76:

• AC/PC, USA adapter, 4 pin - 010-10277-00 This adapter allows you to connect your GPS unit to AC power (U.S., 110-volt) and to your PC. Features standard 9-pin D connector.
• GA 27C low profile remote automobile antenna - 010-10052-05 This new and improved remote antenna runs on a lower voltage so battery drain is minimized. Comes with two mounting options. Magnetic mount for the outside of your vehicle or boat. Suction mount holds antenna in place against the inside of your windshield or window. With 8 feet of cable and MCX connector. Size: 2.75"L x 2"W x .75"H.
• GA 26/27 series trunk lip antenna mount - 010-10061-00 The magnetic mounts that come with our GA 26/27 and GA 26C/27C remote antennas are pretty strong, but if you think your adventures demand even more stability, check out this trunk lip mount. This one-piece mount slips over the edge of the trunk or other surface and is held in place by 2 locking screws.
• GA 26/27 series flange antenna mount - 010-10062-00 If you're mounting a GA 26/27 and GA 26C/27C antenna to a thin surface, such as the outside of an RV, boat, or car, add some structural strength with this sturdy, one-piece flange mount.
• Marine Mount - 010-10300-00 Free up your hands to drive the boat, fish, or just enjoy your time on the water. This adjustable marine mount swivels and tilts for optimum viewing and has a locking mechanism to keep unit secure. Accepts optional external power adapter for quick connection to a DC power supply.
• Power/data cable - 010-10082-00 This power and data cable has bare wires at the end so you can hard wire your GPS directly to a DC power source or some other electronic device. This allows you to send speed and position data to devices such as a chartplotter, computer, auto pilot, radar, etc.
• Cigarette lighter adapter - 010-10085-00 Save a battery's life—buy an adapter. Plugs into any standard cigarette lighter receptacle to power your GPS.
• Handlebar mount bracket - 010-10305-01 Snap your GPS unit into this secure handlebar mount and it's ready to ride. Mount fits up to a one-inch diameter bar and is perfect for your bike, motorcycle or ATV. Includes hardware and instructions.
• PC interface cable with cigarette lighter adapter - 010-10165-00 This cable allows you to make a powerful connection between your GPS and your PC. Create routes and waypoints on your PC and transfer them to your GPS. You can also download map detail from MapSource CD-ROMs to compatible units. Cable features a standard 9-pin D connector. Connects to any 12-volt receptacle.
• Auto Navigation kit - 010-10509-01 Auto navigation kit (City Select NA, full unlk, friction mount, dash mount and 12-volt power cable)
• Data Cable (bare data wires) - 010-10086-00 This data cable has bare wires at the end so you can hard wire your GPS directly to another electronic device. This allows you to send speed and position data to devices such as a chartplotter, computer, auto pilot, radar, etc. Data cable doesn't have power — you'll have to run off your unit's batteries.
• PC interface cable - 010-10141-00 This cable allows you to make a powerful connection between your GPS and your PC. Create routes and waypoints on your PC and transfer them to your GPS. You can also download map detail from MapSource CD-ROMs to compatible units. Cable features a standard 9-pin D connector. Does not provide wiring for external power.
• Data transfer cable (unit to unit) - 010-10142-00 This is how we make our GPS units talk to one another. Say your buddy has some great fishing spots saved as waypoints and you want to transfer them to your GPS. This cable bridges the gap so you can transfer data such as waypoints, routes, and tracks between GPS units.
• Carrying case - 010-10117-02 Save your handheld GPS or FRS from some of the scuffs and scrapes it could pick up in the line of duty. This nylon carrying case protects your unit while in storage or in the field. Features a wide zippered opening and a belt loop for accessibility and portability.
