Zodiac Flatpack Liferafts
 |
 |
 |
 |
 |
|
Zodiac Flatpack Liferafts
Zodiac Flatpack Liferafts have been introduced to meet the increasing demands of smaller vessels with a minimum amount of stowage space.
Zodiac Flatpack Liferafts have been designed using the very latest construction and packing techniques to ensure that the size is kept to the absolute minimum for easy stowage in a very confined space.
SOLAS A or B emergency pack options are available in sizes from 6 to 16 persons.
Zodiac Flatpack Liferafts offer
low ownership cost through advanced materials and superior manufacturing methods.
Zodiac’s thermobonding construction coupled with polythene-coated fabrics make
these liferafts especially resistant to ageing. Lighter but stronger fabrics
also allow Zodiac Liferafts to be packed into smaller containers, thus saving valuable
space. Cellular foam floors ensure protection against extremes of cold whilst
also maintaining thermo properties if damaged, unlike inflatable floors.
Zodiac
Liferafts are approved by the world's leading Maritime Authorities.
|
Zodiac Flatpack Liferafts |
Persons |
A Pack
|
|
B Pack
|
|
|
Size
(mm) |
Weight
(kg) |
Size
(mm) |
Weight
(kg) |
|
6
|
940
x 570 x 370 |
67 |
940
x 570 x 370 |
50 |
|
8
|
1060
x 640 x 380 |
76 |
940
x 570 x 370 |
57 |
|
10
|
1160
x 730 x 450 |
93 |
1060
x 640 x 380 |
63 |
|
12 |
1160
x 730 x 450 |
125 |
1160
x 730 x 390 |
93 |
|
16 |
1160
x 730 x 450 |
135 |
1160
x 730 x 390 |
93 |
