The high-resolution visual display where contrast can be adjusted and as standard shows: Channel no./Frequency/Volume setting/Power setting/Battery state.
Additionally, via the function menu, the operator can set: Watch - single/dual or triple selection/Private channel selection/Contrast backlighting selection with timer/Keytone selection/Battery type fitted/Unit internal temperature/Actual battery voltage.
|
Specification |
||
|
Parameter |
Tron TR20 GMDSS |
Tron TR20 Plus |
|
General |
||
|
Conforming standard: |
ETS 300 225 |
EN 301 178 |
|
Frequency range: |
156–163 MHz |
156–163 MHz |
|
Channel spacing: |
25 kHz (12.5 kHz optional) |
25 kHz (12.5 kHz optional) |
|
No. channels |
19 |
54 |
|
Operating temperature range: |
–20 to +55°C |
–20 to +55°C |
|
Battery life: |
> 8 hours (lithium battery |
> 7 hours |
|
2W power output, 10-10-80) |
(1500 mAh NiMH battery |
|
|
5W power output, 5-5-90) |
||
|
Antenna connector: |
SMA |
SMA |
|
Microphone connector: |
2.5-mm jack |
|
|
Headset connector |
3.5-mm jack |
|
|
AF output power internal: |
>200 mW |
|
|
AF output power external: |
>100 mW |
|
|
Weight: |
Approx. 350 g |
Approx. 420 g |
|
with lithium battery |
with NiMH battery |
|
|
Transmitter |
||
|
RF output power: |
1 W (Lo)/2 W (Hi) |
1 W (Lo)/5 W (Hi) |
|
Harmonics and spurious: |
<0.25 µW |
< 0.25 µW |
|
Frequency error: |
< +1.5 kHz |
< +1.5 kHz |
|
Receiver |
||
|
Maximum useable sensitivity: |
< 1 µV for 20 dB Sinad |
< 1 µV for 20 dB Sinad |
|
Adjacent channel rejection: |
> 70 dB |
> 70 dB |
|
Blocking: |
> 90 dB |
> 90 dB |
|
Spurious response: |
> 70 dB |
> 70 dB |
|
Harmonic distortion: |
< 5% |
< 5% |
|
Intermodulation rejection: |
> 68 dB |
> 68 dB |
| 99900 | Tron TR20 Plus |
| 80060 | Tron TR20 Emergency Lithium Battery 5-year maintenance kit |
| 80059 | NiMH battery 7.2 V/1,500 mAh |
| 80098 | Test Battery |
| 99920 | RCH-20 dual-slot fast charger 12-24 VDC includes DC Cable |
| 80080 | AC adaptor for RCH-20, 220VAC Euro Style (2 pin) |
| 80081 | AC adaptor for RCH-20, 220VAC UK Style (3 pin) |
| 80364 | Floating carry case, neoprene, red or black |
| 80085 | Fist microphone |
| 80818 | Earpiece headset |
| Spare parts: | |
| 99880 | Antenna |
| 80083 | Wrist strap |
| 80078 | Operator's manual |
| 80817 | Wall bracket |
If you have any questions regarding any Jotron products, please call or mail us and we will be pleased to answer promptly.
